These high performance monocrystalline solar panels are much smaller, thinner, higher in efficiency and more affordable than our previous models. The manufacturing process for this range uses 36 pieces of 156x156mm A-grade solar cells cut into defined sizes with 4 grid lines, which provides excellent performance under low light environments. Each panel is designed to withstand harsh environmental conditions with a durable anodised aluminium frame and 3.2mm low iron tempered glass. The glass is anti-reflective and has a hydrophobic effect to resist dirt and dust, improving light absorption thereby preventing any needless power loss. The anti-reverse charging diode in the junction box prevents the 12V battery to reverse charge solar panels in the night or when sunlight is low. The entire range is easier to install with minimal ongoing maintenance and compatible with industry standard inverters and mounting systems.
Product Specifications
- DC Voltage : 12.0V
- Continuous Power : 40.0W
- Length : 664.0mm
- Width : 408.0mm
- Height : 25.0mm
- Cable length : 0.9m
- Solar panel type : Monocrystalline
- Mounting Method : Standard Universal
- Mounting Material : aluminium
- Cover Material : tempered glass
- Open Circuit Voltage : 21.5V
- Short Circuit Current : 2.5A
- Voltage at Power Max : 17.2V
- Current at Power Max : 2.33A
- Power Connector : 4mm PV Connector (MC4 Style)
- Bypass Diode Included : true
- Length : 68 cm
- Width : 42 cm
- Height : 4 cm
